Carbon Scout Pro 15000lb Winch and Recovery Gear
Carbon Scout Pro 15000lb Winch and Recovery Gear
The Carbon Offroad Scout Pro 15000lb Winch delivers controlled recovery power for heavy off-road platforms like RAM 1500 trucks, 79 Series Land Cruisers, and slide-on campers. Engineered with a 12-volt 7-horsepower series-wound motor and a 218:1 three-stage planetary gearset, it handles sustained pulls up to 6804kg while maintaining reliable line speed across multiple cable layers. An integrated automatic brake and rotating ring gear clutch enable precise load control without stressing vehicle frames.
Built for extreme conditions, the assembly meets IP68 standards to repel dust and water while drawing 65 amps at idle and scaling to 380 amps under maximum tension. A 24-meter section of 11mm high-strength UHMWPE synthetic rope routes through a hard-anodized MEGAPRO fairlead and locks securely into a forged rope thimble. Included wired and wireless remotes provide flexible operation from inside the cab or standing near the equipment.
📋 Product summary:
- Rated single-line pull of 6804kg (15000lbs) across four drum passes
- Three-stage planetary gearing delivering a 218:1 mechanical advantage
- 24-meter length of 11mm UHMWPE synthetic recovery cable
- Hard-anodized aluminum MEGAPRO fairlead with forged replacement hook
- IP68 waterproof sealing protecting sensitive motor components
- Lifetime mechanical guarantee covering five years of electrical systems
| Feature | Specification Metric (Imperial) |
|---|---|
| Part Number | CW-XD15-V3WO |
| Rated Line Pull | 6804kg (15000lbs) |
| Motor | 12V DC 7HP Series-Wound |
| Gear Ratio | 218:1 |
| Recommended Battery | Minimum 650 CCA |
| Mounting Bolt Pattern | 254mm x 114.3mm (10.0" x 4.5") |
| Drum Dimensions (Diameter x Length) | 63.5mm x 224mm (2.5" x 8.8") |
| Winch Dimensions (L x W x H) | 556.5mm x 158mm x 187mm (21.9" x 6.2" x 7.4") |
| Packing Dimensions (L x W x H) | 580mm x 200mm x 220mm (22.8" x 7.9" x 8.7") |
| Installed Weight | 26.7kg (58.9lbs) |
| IP Rating | IP68 |
| Line Pull Metric (Imperial) | Line Speed Metric (Imperial) | Motor Current |
|---|---|---|
| 0kg (0lbs) | 8.5m/min (27.9fpm) | 65 amps |
| 910kg (2000lbs) | 3.6m/min (11.8fpm) | 120 amps |
| 2720kg (6000lbs) | 2.9m/min (9.5fpm) | 160 amps |
| 4540kg (10000lbs) | 2.0m/min (6.6fpm) | 215 amps |
| 5900kg (13000lbs) | 1.4m/min (4.6fpm) | 265 amps |
| 6818kg (15000lbs) | 1.1m/min (3.6fpm) | 380 amps |
| Layer | Line Pull Metric (Imperial) |
|---|---|
| 1 | 6810kg (15000lbs) |
| 2 | 5765kg (12700lbs) |
| 3 | 4890kg (10770lbs) |
| 4 | 4145kg (9130lbs) |
